NHF型星空登录官网

产品简介

产品介绍(Product Introduction)根据客户提出的设备大容积要求,第二代NHF系列星空登录官网终于诞生,该分离机利用螺旋与斗轮机原理,能够一次性骨料分离,完全满足客户的生产需求。According to large volume requi···

详细介绍在线留言

产品介绍(Product Introduction

根据客户提出的设备大容积要求,第二代NHF系列星空登录官网终于诞生,该分离机利用螺旋与斗轮机原理,能够一次性骨料分离,完全满足客户的生产需求

According to large volume requirements of the equipment proposed by the customers, the second generation NHF series sand and gravel separator has thus emerged. The separator uses the principle of spiral and bucket wheel machine to separate aggregates at one time, thus to fully meet the production needs of customers.



     创新的导流式滚筒筛,处理大方料时,不易堵塞Innovative diversion conical screen is not easily blocked when handling large materials

     斗式出料口的应用,实现无摩擦运行,降低能耗Bucket outlets are designed for frictionless operation, thus to reduce energy consumption

     大容积机体设计,沉降效果好,溢流出砂少Large-volume body design is with good settlement effect and less spilled sand



主要参数(Main Parameters

1

分离机规格型号Type)

NHF-I型分离机

NHF-II型分离机

NHF-III型分离机

2

处理能力Screening capability)

>30m3/h

>30m3/h

>30m3/h

3

分石尺寸Stone size screened)

>6mm

>6mm

>6mm

4

分砂尺寸Sand size screened)

<6mm

<6mm

<6mm

5

搅拌车数量(Mixing trucks number)

15——30台

30——60台

60——100台

6

设备总功率(Power)

13.5kw

16.5kw

19.5kw

7

设备总重量(Weight)

5000kg

5500kg

6000kg
